Ram?-hart Contact Angle Goniometer and Tensiometer Products

 ram?-hart precision contact angle goniometers and tensiometers are backed by nearly 50 years of experience and reputation. ram?-hart was the first company in the world to manufacture a contact angle goniometer based on the NRL design of Dr. William Zisman. Today nearly five of decades of experience are bundled in each contact angle goniometer and tensiometer. ram?-hart only makes surface science tools for measuring contact angle and surface tension. That is our sole focus. Our machinists and instrument technicians hand build and assemble each unit to rigid specifications. No goniometer system will ship from our facility until it has been thoroughly tested and calibrated and every component is in proper working order. ram?-hart is the world-wide leader in surface science instruments and contact angle goniometers.



Please refer to the matrix below to better understand the differences between the various goniometer and goniometer / tensiometer (G/T) instruments.



ram?-hart Product Matrix
Measures Contact Angle
Measures Surface Energy (using suite of six SE tools)	?
Measures Surface Tension and Interfacial Tension	?	?				?
Includes U1 Series SuperSpeed Digital Camera at 100 fps
Goniometer or Goniometer / Tensiometer	G	G	G/T	G/T	G/T	G	G/T	G/T
Edition of DROPimage: CA, STD (Standard) or ADV (Advanced)	CA	STD	ADV	ADV	ADV	STD	ADV	ADV
System includes PC & LCD
Supports 210fps G1 Series High Speed Upgrade Kit (p/n G1-KIT)
16" or 21" Optical Bench	16"	16"	16"	16"	16"	21"	21"	21"
Supports Manual Tilting Base					n/a			n/a
Supports Automated Tilting Base		?			Std			Std
Standard Precision 3-Axis Locking Leveling Leveling Stage
Advanced Precision Graduated Heavy Duty 3-Axis Stage with fine and course vertical adjustment and Leveling
Includes Manual Microsyringe Dispensing
Supports optional Automated Dispensing System	?				Std			Std
Supports optional Oscillator		?				?
Supports Environmental Fixture
Supports Environmental Chamber
Supports Advanced Chamber
Supports all modular accessories
Maximum Wafer Support (diameter)	4"	4"	4"	4"	4"	12"?	12"	12"
Supports Vacuum Chuck 6" or 8"
Includes 1-year Parts and Labor Warranty and Priority Software Support
Halogen Fiber Optic Illuminator
Available in 115V and 230V
? - requires software upgrade ? - Model 400 includes an 8" Wafer Support but supports up to 12".



Note that all current goniometer models ship with a microsyringe fixture (p/n 100-10) and microsyringe assembly (p/n 100-10-20) for manual dispensing. A wide variety of needles are available. See our chart here: www.ramehart.com/pdf/needles.pdf. The optional software-driven Automated Dispensing System is supported on Models 200 and up.



In surface science, an instrument called a contact angle goniometer is used to measure static contact angle, advancing and receding contact angle, and in some cases, surface energy. The root goni refers to "angle" while meter refers to measuring device. Thus a goniometer is a measuring device for angles. While the term has been used to describe a tool used by physical therapists and also for measuring other types of angles, the traditional and more prominent use of the word "goniometer" has been to describe a contact angle meter. Note that while all of our instruments are goniometers, Models 190 and 200 are goniometer instruments only (not goniometer / tensiometer).



A goniometer / tensiometer is an instrument that can measure both contact angle as well as surface tension and interfacial tension. Models 250, 260, 500, and 590 are all goniometer / tensiometer instruments. All of these models ship with DROPimage Advanced software. This powerful program calculates surface and interfacial tension using a standard PC. The method used is based on the Young-Laplace equation and the program has been designed to handle pendant, inverted pendant, sessile, and captive bubble drops. DROPimage Advanced is methods-based allowing full control over every aspect of the experiment allowing for sophisticated dynamic and time-dependant studies. Results include surface tension, interfacial tension, contact angle, surface energies of solids, drop dimensions, volume and surface area, as well as surface dilatational elasticity and viscosity. Full control over the Automated Dispensing System and the Automated Tilting Base accessories is integrated into the software allowing them to be controlled via discrete controls or via a methods-based experiment. The Automated Dispensing System and the Automated Tilting Base are included with Model 290 and 590 but are sold separately with all other models including Model 250, 260 and 500. DROPimage Advanced has all of the surface energy tools included with DROPimage Standard.
